YAQIN MS-12B Tube PreAmplifier/RIAA


Ability to use with CD/DVD player as a preamplifier andwith MM cartridge turntable as a phono stage. Dual stereo outputs either 0.7V for a post stageamplifier or 0.25V for an integrated amplifier. It can be applied to bi-ampconfiguration. Employ DC filaments power supply to minimize hummingnoise. Adopts conventional active RIAA equalization in phonostage circuit.

Power transformers manufactured with silicon steelsheet and high quality oxygen-free enameled copper wire. Utilizes the audiophile capacitors, such asJapanese Nippon Chemi-con capacitor filters, and high quality metalprecision resistors dedicated for audio frequency. Applies special potentiometer as volume controller withlow noise and durable. Beautiful aluminum heavy duty chassis, faceplate, andbezels. Tubes:12AX7 × 2(Phono voltage amplifier).

Output Voltages: Dual outputs of either 0.25V or 0.7V. 0.25V(for integrated amplifier).

0.7V(for power amplifier or second gear). Output Jacks: Two channels two group gold plated RCAjacks. Input Jacks: Two Groups gold plated RCA jacks (CD/DVD andPhono). Frequency Response: 15Hz 100KHz (-2.0dB). Signal-to-Noise Ratio: >75dB (CD/DVD input 0.5V1KHz, output 0.7V).

>65dB(Phono input 10mV 1KHz, output 0.7V). Phono Stage Suitability: MM cartridge phonograph.

Weight: 3.0kg (7.7lb). Dimension: 17cm(W) x 38cm(D) x 16cm(H).
